The Plasmatherm TCP is a DRY thawing and warming device with integrated documentation software for data capture.  The device is designed to thaw plasma, cell products and other blood components.

The Plasmatherm TCP is a DRY thawing and warming device with integrated documentation software for data capture.  The device is designed to thaw plasma, cell products and other blood components.

Plasmatherm TCP

Data Integrated Thawing Device

Product Plasmatherm TCP
Catalog#

46-212.10052

Quantity 1/Box
Optional Accessories

Data Capture Bar Code Scanner & Printer

Barcode Reader Software Documentation
Log Printer

Compact Design

Thawing Bag 10″ wide x 15″ high
  • Description
  • Specifications
  • Accessories

A unique, dry technology that offers electronic documentation for the thawing and warming process.

The TCP Plasmatherm provides data recording via an Ethernet port which automatically records the SN, Program, date, start/end time, start temperature, maximum temperature, end temperature and special events, eg. opening the lid, changes made to the heating duration, error codes. The optional bar code scanner can record Operator ID and sample ID’s for up to 8 individual samples.

Special Features
• NO direct contact with water
• ONLY change thawing solution once per year
• Customizable user settings
• Maintains a constant 37°C

• Clear cover chamber provides viewing of thawing process
• Designed for continuous operation
• Corrosion resistant
• Leak detection, auto shut off & overheat alarms

Logging Tool Overview
• Record who, when, what and how much you have thawed
• Record of user ID and/or barcodes of samples
• Documentation of date, time, temperature and selected program
• Auto recording of all changes made on TCP device
• Export your data or access previously saved data
• 14 available languages
• Compatible with Windows 7, 8, 10

Product Applications
• Thawing of fresh frozen plasma
• Thawing of Octaplas™ (S/D treated pooled plasma)
• Thawing of plasma frozen within 24 hours after phlebotomy
• Thawing of cryoprecipitated AHF
• Warming of whole blood
• Warming of red blood cells
• Warming of crystalloid infusion solutions prior to transfusion

Optional Accessories
• Data Capture Bar Code Scanner & Printer
• GenesisBPS Overwrap Bags

Model: Plasmatherm TCP
Power supply: 100-120 VAC  50/60 Hz
Temperature setting: Default: +37°C
Range: +30°C to max. +37°C
Temperature accuracy: ± 0.5°C
Interfaces/devices:
(optional)
TCP Logging Tool (for Ethernet-port only), Barcode scanner, Log printer
Dimensions (WxDxH): 340 x 600 x 320 mm
Weight without filling: 18 kg
Filling quantity: 9 liters (DI water)
Safety class: I
Identification: CE 0123
Certifications: CE0123; ISO 9001; ISO 13485

Plasma Guard Thawing Bags are specifically designed for thawing fresh frozen plasma and cryoprecipitate in a controlled temperature water bath.

Product Data Capture Bar Code Scanner & Printer
Quantity 1 Each
Product  Plasma Guard Thawing Bags
Thawing Bag 10″ wide x 15″ high
Quantity 1000 bags / roll”
DESCRIPTION
SPECIFICATIONS
ACCESSORIES
DESCRIPTION

The Plasmatherm offers a unique technology that uses a contained sealed system and replaces the use of open water baths.

The Plasmatherm expands the GenesisBPS product portfolio of blood collection and processing equipment to increase the efficiency and accuracy of procedures performed by health care technicians.

Special Features
• NO direct contact with water
• ONLY change thawing solution once per year
• Customizable user settings
• Maintains a constant 37°C

• Clear cover chamber provides viewing of thawing process
• Designed for continuous operation
• Corrosion resistant
• Leak detection, auto shut off & overheat alarms


Product Applications
• Thawing of fresh frozen plasma
• Thawing of Octaplas™ (S/D treated pooled plasma)
• Thawing of plasma frozen within 24 hours after phlebotomy
• Thawing of cryoprecipitated AHF
• Warming of whole blood
• Warming of red blood cells
• Warming of crystalloid infusion solutions prior to transfusion


Optional Accessories
• Data Capture Bar Code Scanner & Printer
• GenesisBPS Overwrap Bags

SPECIFICATIONS

SPECIFICATIONS

Type:

Plasmatherm

Mains supply: 230 V AC / 115 V AC
Mains frequency: 50-60 Hz
Temperature setting: +30 to max. +37 °C
Interfaces / devices: Optional RS 232, barcode scanner, log printer, Ethernet connection
Dimensions (WxDxH): 340 x 600 x 320 mm
Weight without filling: 18 kg
Filling quantity: 9 l
Safety class: I
Identification: CE 0123
Certification ISO 9001 ISO 13485



ACCESSORIES

Plasmatherm Accessories

Plasma Guard Thawing Bags are specifically designed for thawing fresh frozen plasma and cryoprecipitate in a controlled temperature water bath.

Product Data Capture Bar Code Scanner & Printer
Quantity 1 Each

Product  Plasma Guard Thawing Bags
Thawing Bag 10" wide x 15" high
Quantity 1000 bags / roll"
